Weldmate HG1401DA ARC/TIG Inverter Welder

The SIP HG1401DA ARC Inverter Welder is a powerful multi-functional inverter with a lightweight, compact design for portability, and is generator-friendly meaning it is ideal for a variety of applications and environments without mains electricity supplies.

KEY FEATURES

20A to 140A output current; 140A @ 60% duty cycle
Lift-TIG start function and anti-stick circuitry
Fitted with a reliable Voltage Reduction Device (VRD)
Generator-friendly for suitability in all environments
Thermal overload protection for added safety Full Specification
The SIP HG1401DA ARC Inverter Welder is a powerful multi-functional inverter with a lightweight, compact design for portability, and is generator-friendly meaning it is ideal for a variety of applications and environments without mains electricity supplies.

Supplied with electrode holder and cable, plus Earth cable and clamp accessories. Ø 1.6mm to Ø 3.2mm electrode diameter
20A to 140A output current; 140A @ 60% duty cycle
Lightweight and compact design for simple portability
Lift-TIG start function and anti-stick circuitry
Fitted with a reliable Voltage Reduction Device (VRD)
Generator-friendly for suitability in all environments
Thermal overload protection for added safety
Equipped with high-quality dinse sockets
SIP 2-Year Standard Silver Warranty Technical Information
ITEM NO. 05711
Input Supply: 230v (13A)
Output Current: 20A – 140A
Output Voltage: 20.8v – 25.6v (ARC)
10.8v – 15.6v (TIG)
Duty Cycle: 20°C: 140A @ 60%
40°C: 140A @ 20%
Electrode Diameter: Ø 1.6mm – 3.2mm
Welding Thickness: 1.5mm – 7mm
Open Circuit Voltage: 69v
Power Factor: 0.75
Efficiency Level: 85%
Protection Level: IP21S
Insulation Class: Class H
Net Weight: 4.80kg
Gross Weight: 6.80kg
Product Dimensions:
Packaged Dimensions: 310(H) x 436(W) x 211mm(D)
